VDE socket wrench insert 1/2" 6-point 10 mm

VDE 19 10 / Code no. 6122510
VDE socket wrench insert 1/2" 6-point 10 mm - 6122510 (1)
VDE socket wrench insert 1/2" 6-point 10 mm - 6122510 (2)
VDE socket wrench insert 1/2" 6-point 10 mm - 6122510 (1) (Thumbnail)
VDE socket wrench insert 1/2" 6-point 10 mm - 6122510 (2) (Thumbnail)

VDE socket wrench insert 1/2" 6-point 10 mm

VDE 19 10 / Code no. 6122510
Price on request
BUY ONLINE Find A Dealer
Product line
EAN 4010886612255
Product description
  • Hexagonal, manually operated
  • With square drive as per DIN 3120 - C 12.5, ISO 1174
  • GEDORE vanadium steel 31CrV3
  • Protective insulation up to 1000 V, according to EN 60900/IEC 60900, 2-fold Check-Tool insulation
  • 16 - 18 mm insulation overhang
  • The diameter d1 for the dimensions 27, 30 and 32 is not standardized
  • Dimensions and weights
    • Total width [mm]: 27 mm
    • Total length [mm]: 54 mm
    • Weight [kg]: 0,06 kg
  • Scope of delivery
    • Contents (Qty of pieces): 1
  • Technical characteristics
    • Drive mount, square [metric]: 12,5 mm
    • Drive connector square [inch]: 1/2"
    • Execution: VDE insulated up to 1000 V
    • Working length: 54,0 mm
    • Insert-Ø 1: 19,5 mm
    • Insert-Ø 2: 27,0 mm
    • Material: Chrome‑vanadium steel 31CrV3
    • Standard: DIN 3120 – C 12,5 ISO 1174 EN 60900/IEC60900
    • Surface: double check‑tool insulation
    • Width across flats 1 [mm]: 10
    • Safety: Kugelfangrille

Available variants

VDE socket wrench insert 1/2" 6-point 10 mm - 6122510
VDE socket wrench insert 1/2" 6-point 10 mm
6122510 / VDE 19 10
Price on request
‌
VDE socket wrench insert 1/2" 6-point 11 mm - 6122780
VDE socket wrench insert 1/2" 6-point 11 mm
6122780 / VDE 19 11
Price on request
‌
VDE socket wrench insert 1/2" 6-point 12 mm - 6122860
VDE socket wrench insert 1/2" 6-point 12 mm
6122860 / VDE 19 12
Price on request
‌
VDE socket wrench insert 1/2" 6-point 13 mm - 6122940
VDE socket wrench insert 1/2" 6-point 13 mm
6122940 / VDE 19 13
Price on request
‌
VDE socket wrench insert 1/2" 6-point 14 mm - 6123080
VDE socket wrench insert 1/2" 6-point 14 mm
6123080 / VDE 19 14
Price on request
‌
VDE socket wrench insert 1/2" 6-point 15 mm - 6123160
VDE socket wrench insert 1/2" 6-point 15 mm
6123160 / VDE 19 15
Price on request
‌
VDE socket wrench insert 1/2" 6-point 16 mm - 1439294
VDE socket wrench insert 1/2" 6-point 16 mm
1439294 / VDE 19 16
Price on request
‌
VDE socket wrench insert 1/2" 6-point 17 mm - 6123240
VDE socket wrench insert 1/2" 6-point 17 mm
6123240 / VDE 19 17
Price on request
‌
VDE socket wrench insert 1/2" 6-point 19 mm - 6123320
VDE socket wrench insert 1/2" 6-point 19 mm
6123320 / VDE 19 19
Price on request
‌
VDE socket wrench insert 1/2" 6-point 22 mm - 6123400
VDE socket wrench insert 1/2" 6-point 22 mm
6123400 / VDE 19 22
Price on request
‌
VDE socket wrench insert 1/2" 6-point 24 mm - 6123590
VDE socket wrench insert 1/2" 6-point 24 mm
6123590 / VDE 19 24
Price on request
‌
VDE socket wrench insert 1/2" 6-point 27 mm - 6123670
VDE socket wrench insert 1/2" 6-point 27 mm
6123670 / VDE 19 27
Price on request
‌
VDE socket wrench insert 1/2" 6-point 30 mm - 6123750
VDE socket wrench insert 1/2" 6-point 30 mm
6123750 / VDE 19 30
Price on request
‌
VDE socket wrench insert 1/2" 6-point 32 mm - 6123830
VDE socket wrench insert 1/2" 6-point 32 mm
6123830 / VDE 19 32
Price on request
‌
