Combination spanner UD-Profile 7/32"
7 7/32AF
/ Code no. 1436775
Combination spanner UD-Profile 7/32"
7 7/32AF
/ Code no. 1436775
Price on request
Product line
EAN
4010886805589
Product description
- Acc. to DIN 3113, Form A, ISO 3318, ISO 7738
- Chrome-vanadium steel 31CrV3, chrome-plated
- Carefully forged and professionally machined
- Slim jaw and jaw walls make this spanner lighter overall
- Overloading indicated by deformation
- Secure grip thanks to hollow shaft - very ergonomic and handy
- Glare-free look due to matt chrome
- Carefully forged and professionally machined
- High industrial quality for heavy continuous stress
-
Dimensions and weights
- Total width [mm]: 14 mm
- Total height [mm]: 5 mm
- Total length [mm]: 92 mm
- Weight [kg]: 0,011 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Width of head 1 [mm]: 9,7 mm
- Width of head 2 [mm]: 13,2 mm
- Head height 1 [mm]: 3,6 mm
- Head height 2 [mm]: 3,6 mm
- Material: Chrome‑vanadium steel 31CrV3
- Mouth position 1: 15°
- Standard: similar to DIN 3113 - form A ISO 3318 ISO 7738
- Surface: chrome‑plated
- Compliance: compliant
- Ring profile: hexagonal
- Ring angle: 15°
- Width across flats 1 [AF]: 7/32"
