Ratchet head 3/8" anti-clockwise
754-11
/ Code no. 7686770
Ratchet head 3/8" anti-clockwise
754-11
/ Code no. 7686770
Price on request
Product line
EAN
4002805754115
Product description
- Socket:
- Enables controlled torque tightening in combination with a DREMOMETER torque wrench
- Features:
- Fine-pitched, sturdy ratchet head
- Made of chrome-vanadium steel
- Clockwise models (No. 754-00 to -06)
- Anti-clockwise models (No. 754-11 to -16)
- Made of chrome-vanadium steel
- Scope of delivery:
- Ratchet head
- Single packed in poly-bag
- *Max. continuous load of ratchet according to DIN EN ISO 6789:2003 and/or maximum load of cavity
-
Dimensions and weights
- Total height [mm]: 40 mm
- Weight [kg]: 0,16 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Drive mount, square [metric]: 10,0 mm
- Drive connector square [inch]: 3/8"
- Drive connector square [metric]: 10 mm
- Drive square inch: 3/8"
- Number of teeth: 18
- Execution: left‑hand thread
- Continuous load: 3/8" = 135 N·m
- Head height 1 [mm]: 28 mm
- Diameter of head 1: 35 mm
- Material: Chrome‑vanadium steel
- Standard: DIN EN ISO 6789
- Compliance: compliant
- Return angle: 20 °
- Use: AL
