VDE Reversible ratchet 3/8"
VDE 3093 U
/ Code no. 2946599
VDE Reversible ratchet 3/8"
VDE 3093 U
/ Code no. 2946599
Price on request
Product line
EAN
4010886947814
Product description
- Smooth running and robust
- Secure holding of the attachments due to push-button locking with ball in the square drive
- Direction changed by 2 push-buttons, marked R and L, on the shaft
- Square drive acc. to DIN 3120 - A 10, ISO 1174, chrome-vanadium steel 31CrV3
- Practical set of insulated up to 1000 V, according to EN 60900/IEC 60900, sheath insulation mm position
-
Dimensions and weights
- Total length [mm]: 185 mm
- Weight [kg]: 0,22 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Drive connector square [metric]: 10 mm
- Drive square inch: 3/8"
- Push-button release: Yes
- Material: Chrome‑vanadium steel 31CrV3
- Standard: DIN 3120 - A 10 ISO 1174 EN 60900/IEC60900
- Compliance: compliant
- Return angle: 8,2 °
