Hydraulikaggregat Type LHU-30 A
LHU-30 A
/ Code no. 20900.000
Hydraulikaggregat Type LHU-30 A
LHU-30 A
/ Code no. 20900.000
Price on request
Product line
Product description
- The patented automatic control system contains the necessary sensor technology to tighten any screw connection fully automatically at the push of a button, regardless of the hydraulic wrench and manufacturer. The operator is visually informed about the end of the tightening process.
- One-handed operation
- With new type of cooling air duct
- Completely closed protective housing
-
Dimensions and weights
- Total width [mm]: 240 mm
- Total height [mm]: 380 mm
- Total length [mm]: 400 mm
- Weight [kg]: 27,2 kg
-
Scope of delivery
- Parts list (Text): The hydraulic unit is delivered oil-filled and ready for use.
- Contents (Qty of pieces): 1
-
Technical characteristics
- Connection voltage [Hz]: 50
- Supply voltage V: 230 V
- High pressure l/min [bar]: 0,8/800
- Low pressure l/min [bar]: 1,7/320
- Compliance: compliant
- Tank size [l]: 2,5 l
