Socket wrench reversible ratchet SE 9x12 13 mm
SUKSE9 13
/ Code no. 2827743
Socket wrench reversible ratchet SE 9x12 13 mm
SUKSE9 13
/ Code no. 2827743
Price on request
Product line
EAN
4002805933121
Product description
- Flat ring ratchet with UD-profile, fine-toothed
- With lowered change-over lever for right/left rotation
- Enables quick suit without reattachment
- Non-glare look due to matt chrome-plating, locking insert and pawl manganese-phosphated
- GEDORE vanadium steel 31CrV3, forged
- In combination with a 9x12 mm torque wrench or 9x12 mm plug-in handle (AGSE9)
- Forged
- To operate with a 9x12 mm torque wrench or rectangular handle 9x12 mm
-
Dimensions and weights
- Total width [mm]: 25,7 mm
- Total height [mm]: 20,3 mm
- Total length [mm]: 70,5 mm
- Weight [kg]: 0,08 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Drive connector rectangular: 9 x 12
- Number of teeth: 51
- Continuous load: 107 Nm
- Width of head 1 [mm]: 22,0 mm
- Width of head 2 [mm]: 25,7 mm
- Head height 1 [mm]: 15,8 mm
- Head height 2 [mm]: 9 mm
- Material: Chrome‑vanadium steel 31CrV3
- Return angle: 7 °
- Width across flats 1 [mm]: 13
- Depth gauge [metric]: 42,0 mm
