Dual-Clutch Tool Set
KL-0500-90 KB
/ Code no. 3538370
Dual-Clutch Tool Set
KL-0500-90 KB
/ Code no. 3538370
Price on request
Product line
EAN
4046459204817
Product description
- The tool kit enables a professional disassembly or installation and adjustment of double clutches.
- Required, for example, when installing the LuK RepSet 2CT (602 0018 00, 602 0022 00 or 602 0026 00).
-
Dimensions and weights
- Total width [mm]: 304 mm
- Total height [mm]: 104 mm
- Total length [mm]: 391 mm
- Weight [kg]: 5 kg
-
Scope of delivery
- Parts list (Text): 1x KL-0500-606 - Measuring tripod with dial gauge 1x KL-0049-100 A - Impact extractor basic device 1x KL-0500-903 - Connection of gearbox housing 1x KL-0500-900 A - Collet chuck with clamping sleeve 1x KL-0500-901 - Retaining bolt DQ 380/500 1x KL-0500-908 - Retaining bolt DQ 381 1x KL-0500-902 - Retaining bolt DQ 250 2x KL-0500-906 - Mounting hook Ø 5 mm 2x KL-0500-6071 - Closing plug Ø 12 mm 1x KL-0500-905 - Large cone 1x KL-0500-904 - Small cone 1x KL-0500-9090 B LUK - Plastic case
- Storage: Case
- Contents (Qty of pieces): 15
-
Technical characteristics
- Suitability: Audi Cupra Seat Skoda VW
