Socket wrench insert 1/2" 6-point 23 mm length 38 mm

R61002306 / Code no. 3300272

Socket wrench insert 1/2" 6-point 23 mm length 38 mm - 3300272 (1)

Socket wrench insert 1/2" 6-point 23 mm length 38 mm - 3300272 (1) (Thumbnail)

Socket wrench insert 1/2" 6-point 23 mm length 38 mm

R61002306 / Code no. 3300272

Price on request

BUY ONLINE Find A Dealer

Product line

EAN 4060833002721

Product description

Hand-operated, knurled grip
Matt satin chrome-plated on the drive side, driven end brightly polished
Acc. to DIN 3124, ISO 2725-1
Square drive as per DIN 3120 - C 12,5, ISO 1174, with ball retention groove
Chromium vanadium steel

Dimensions and weights
- Total width [mm]: 32 mm
- Total height [mm]: 32 mm
- Total length [mm]: 38 mm
- Weight [kg]: 0,12 kg
Scope of delivery
- Contents (Qty of pieces): 1
Technical characteristics
- Drive mount, square [metric]: 12,5 mm
- Drive connector square [inch]: 1/2"
- Working length: 38,0 mm
- Insert-Ø 1: 31,0 mm
- Insert-Ø 2: 28,0 mm
- Material: Chrome‑vanadium steel
- Standard: DIN 3124 DIN 3120 – C 12,5 ISO 2725-1 ISO 1174
- Surface: matte chrome (drive side) high‑gloss polished (output side)
- Width across flats 1 [mm]: 23
- Safety: Kugelfangrille

Available variants

Socket wrench insert 1/2" 6-point 23 mm length 38 mm - 3300272

Socket wrench insert 1/2" 6-point 23 mm length 38 mm

3300272 / R61002306

Price on request

‌

Socket wrench insert 1/2" 6-point 8 mm length 38 mm - 3300257

Socket wrench insert 1/2" 6-point 8 mm length 38 mm

3300257 / R61000806

Price on request

Socket wrench insert 1/2" 6-point 9 mm length 38 mm - 3300258

Socket wrench insert 1/2" 6-point 9 mm length 38 mm

3300258 / R61000906

Price on request

Socket wrench insert 1/2" 6-point 10 mm length 38 mm - 3300259

Socket wrench insert 1/2" 6-point 10 mm length 38 mm

3300259 / R61001006

Price on request

Socket wrench insert 1/2" 6-point 11 mm length 38 mm - 3300260

Socket wrench insert 1/2" 6-point 11 mm length 38 mm

3300260 / R61001106

Price on request

Socket wrench insert 1/2" 6-point 12 mm length 38 mm - 3300261

Socket wrench insert 1/2" 6-point 12 mm length 38 mm

3300261 / R61001206

Price on request

Socket wrench insert 1/2" 6-point 13 mm length 38 mm - 3300262

Socket wrench insert 1/2" 6-point 13 mm length 38 mm

3300262 / R61001306

Price on request

Socket wrench insert 1/2" 6-point 14 mm length 38 mm - 3300263

Socket wrench insert 1/2" 6-point 14 mm length 38 mm

3300263 / R61001406

Price on request

Socket wrench insert 1/2" 6-point 15 mm length 38 mm - 3300264

Socket wrench insert 1/2" 6-point 15 mm length 38 mm

3300264 / R61001506

Price on request

Socket wrench insert 1/2" 6-point 16 mm length 38 mm - 3300265

Socket wrench insert 1/2" 6-point 16 mm length 38 mm

3300265 / R61001606

Price on request

Socket wrench insert 1/2" 6-point 17 mm length 38 mm - 3300266

Socket wrench insert 1/2" 6-point 17 mm length 38 mm

3300266 / R61001706

Price on request

Socket wrench insert 1/2" 6-point 18 mm length 38 mm - 3300267

Socket wrench insert 1/2" 6-point 18 mm length 38 mm

3300267 / R61001806

Price on request

Socket wrench insert 1/2" 6-point 19 mm length 38 mm - 3300268

Socket wrench insert 1/2" 6-point 19 mm length 38 mm

3300268 / R61001906

Price on request

Socket wrench insert 1/2" 6-point 20 mm length 38 mm - 3300269

Socket wrench insert 1/2" 6-point 20 mm length 38 mm

3300269 / R61002006

Price on request

Socket wrench insert 1/2" 6-point 21 mm length 38 mm - 3300270

Socket wrench insert 1/2" 6-point 21 mm length 38 mm

3300270 / R61002106

Price on request

Socket wrench insert 1/2" 6-point 22 mm length 38 mm - 3300271

Socket wrench insert 1/2" 6-point 22 mm length 38 mm

3300271 / R61002206

Price on request

Socket wrench insert 1/2" 6-point 24 mm length 38 mm - 3300273

Socket wrench insert 1/2" 6-point 24 mm length 38 mm

3300273 / R61002406

Price on request

Socket wrench insert 1/2" 6-point 26 mm length 42 mm - 3300275

Socket wrench insert 1/2" 6-point 26 mm length 42 mm

3300275 / R61002607

Price on request

Socket wrench insert 1/2" 6-point 27 mm length 42 mm - 3300276

Socket wrench insert 1/2" 6-point 27 mm length 42 mm

3300276 / R61002707

Price on request

Socket wrench insert 1/2" 6-point 28 mm length 42 mm - 3300277

Socket wrench insert 1/2" 6-point 28 mm length 42 mm

3300277 / R61002807

Price on request

Socket wrench insert 1/2" 6-point 30 mm length 42 mm - 3300278

Socket wrench insert 1/2" 6-point 30 mm length 42 mm

3300278 / R61003007

Price on request

Socket wrench insert 1/2" 6-point 32 mm length 42 mm - 3300279

Socket wrench insert 1/2" 6-point 32 mm length 42 mm

3300279 / R61003207

Price on request

Socket wrench insert 1/2" 6-point 25 mm length 42 mm - 3300274

Socket wrench insert 1/2" 6-point 25 mm length 42 mm

3300274 / R61002507

Price on request
