Socket wrench insert 1/4" TX E6 length 25 mm
R41200303
/ Code no. 3300103
Socket wrench insert 1/4" TX E6 length 25 mm
R41200303
/ Code no. 3300103
Price on request
Product line
EAN
4060833001038
Product description
- Hand-operated, knurled grip
- Matt satin chrome-plated on the drive side, driven end brightly polished
- Square drive as per DIN 3120 - C 6.3, ISO 1174, with ball retention groove
- Chromium vanadium steel
-
Dimensions and weights
- Total width [mm]: 12 mm
- Total length [mm]: 25 mm
- Weight [kg]: 0,014 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Drive mount, square [metric]: 6,3 mm
- Drive connector square [inch]: 1/4"
- Working length: 25,0 mm
- Insert-Ø 1: 8,2 mm
- Insert-Ø 2: 12,0 mm
- Material: Chrome‑vanadium steel
- Standard: DIN 3120 – C 6,3 ISO 1174
- Surface: matte chrome (drive side) high‑gloss polished (output side)
- Width across flats TX [mm]: E 6
- Safety: Kugelfangrille
