Puller hydraulisch 3-arm 280x310 mm
1.15/4-HSP1
/ Code no. 1392980
Puller hydraulisch 3-arm 280x310 mm
1.15/4-HSP1
/ Code no. 1392980
Price on request
Product line
EAN
4036976110227
Product description
- Tried and tested, particularly strong design for removing discs, wheels, ball bearings etc.
- With technical and economical benefits due to the variable clamping reach and automatic grip of the legs
- Particularly suitable for pulling off V-belt pulleys and flywheels which are mounted on longer shafts
- With the hydraulic spindle, a controlled and safe pulling action is possible at all times
- Also available with standard spindle - Model 1.15
-
Dimensions and weights
- Weight [kg]: 8,1 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Number of arms: 3
- Width of hooked foot [mm]: 32 mm
- Thickness of hooked foot at tip: 3,5 mm
- Usable depth of hooked foot d2 [mm]: 20 mm
- Hydraulic spindle: 1.06/HSP1
- Hydraulic spindle available: Yes
- Width across flats [mm]: 32 mm
- Usable clamping reach [mm]: 310 mm
- Clamping width (max.) external pulling [mm]: 280 mm
- Tractive force (max.) [N]: 17,0 N
- Tractive force (max.) [t]: 10
