Universal puller 2-arm 250x200 mm
1.06/3
/ Code no. 8000740
Universal puller 2-arm 250x200 mm
1.06/3
/ Code no. 8000740
Price on request
Product line
EAN
4036976104202
Product description
- Proven model for safe and fast removal of discs, wheels, ball bearings etc.
- Strong drop forged pattern
- Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required
- Can be used as external and internal puller by repositioning the legs
- Interchangeable legs available for several clamping depths
- Upgradeable with hydraulic spindle (see table)
-
Dimensions and weights
- Total width [mm]: 330 mm
- Total height [mm]: 65 mm
- Total length [mm]: 315 mm
- Weight [kg]: 7,2 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Number of arms: 2
- Width of hooked foot [mm]: 36 mm
- Thickness of hooked foot at tip: 6,5 mm
- Usable depth of hooked foot d2 [mm]: 28 mm
- Hydraulic spindle optional: 1.06/HSP2
- Width across flats [mm]: 27 mm
- Graduation: Yes
- Usable clamping reach [mm]: 200 mm
- Clamping width (max.) external pulling [mm]: 250 mm
- Clamping width a2 (max.) internal pulling [mm]: 330 mm
- Clamping width a2 (min.) internal pulling [mm]: 125 mm
- Spindle thread size: G 3/4 x 280
- Tractive force (max.) [t]: 7,5
