Universal puller 2-armed with hook brake 170x150mm
1.06/21-B
/ Code no. 1956353
Universal puller 2-armed with hook brake 170x150mm
1.06/21-B
/ Code no. 1956353
Price on request
Product line
EAN
4036976120899
Product description
- Strong drop forged pattern
- Puller hook forged from one piece
- With leg brake - prevents unintentional leg slipping. The leg can be slid along the cross-beam at the push of a button
- Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required
- Can be used as external and internal puller by repositioning the legs
- Interchangeable legs available for several clamping depths
-
Dimensions and weights
- Weight [kg]: 2,8 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Number of arms: 2
- Number of hooks: 2
- Execution: 2‑arm
- Hook brake available: Yes
- Width of hooked foot [mm]: 30 mm
- Thickness of hooked foot at tip: 3,5 mm
- Usable depth of hooked foot d2 [mm]: 24 mm
- Hydraulic spindle optional: 1.06/HSP1
- Width across flats [mm]: 22 mm
- Graduation: Yes
- Usable clamping reach [mm]: 150 mm
- Clamping width (max.) external pulling [mm]: 170 mm
- Clamping width a2 (max.) internal pulling [mm]: 220 mm
- Clamping width a2 (min.) internal pulling [mm]: 80 mm
- Spindle Thrust piece type: Spitze
- Spindle thread size: G 1/2 x 210
- Spindle Surface coating: Nitro-carburated
- reversible arms available: Yes
- Tractive force (max.) [t]: 5,0
