Universal puller HIGH POWER 2-armed 350x200 mm
1.04/HP3A
/ Code no. 1868179
Universal puller HIGH POWER 2-armed 350x200 mm
1.04/HP3A
/ Code no. 1868179
Price on request
Product line
EAN
4036976113525
Product description
- Cross-beam especially hardened and tempered allows safe application of extremely high pulling forces and doubles the tensile force capability
- Strong drop forged pattern
- Can be used as external and internal puller by repositioning the legs
- Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required
- Integral legs, with quick-release
- Exchangeable and rotatable thrust piece (ball or tip)
- Spindle thermo-chemically hardened
- Can be retrofitted with hydraulic spindle
-
Dimensions and weights
- Weight [kg]: 7,76 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Number of arms: 2
- Number of hooks: 2
- Execution: 2‑arm
- Load of the entire puller (max.) [t]: 15 t
- Hook can be moved parallel: Yes
- Width of hooked foot [mm]: 36 mm
- Thickness of hooked foot at tip: 6,5 mm
- Usable depth of hooked foot d2 [mm]: 28 mm
- Hydraulic spindle optional: 1.06/HSP2
- Width across flats [mm]: 27 mm
- Quick release lever available: Yes
- Graduation: Yes
- Usable clamping reach [mm]: 200 mm
- Clamping width (max.) external pulling [mm]: 350 mm
- Clamping width a2 (max.) internal pulling [mm]: 420 mm
- Clamping width a2 (min.) internal pulling [mm]: 150 mm
- Spindle holder: G3/4"
- Spindle Thrust piece type: Kugel & Spitze
- Spindle thread size: G3/4x280mm
- Spindle Thread length (usable) [mm].: 280 mm
- Spindle Surface coating: Nitro-carburated
- Spindle Width across flats: 27 mm
- Exchangeable spindle tip: Yes
- reversible arms available: Yes
- Use: For removing drive pulleys, wheels, ball bearings etc.
- Tractive force (max.) [t]: 15
