Quick-release puller 3-arm 160x150 mm
1.07/2-E
/ Code no. 1227335
Quick-release puller 3-arm 160x150 mm
1.07/2-E
/ Code no. 1227335
Price on request
Product line
EAN
4036976106428
Product description
- Industrial quality, 3 arms for optimum load distribution, non-tilting and gentle on material
- Strong, ergonomically shaped cross beam
- Hook red-hot drop-forged
- Self-supporting hooks with T-profile for a form-fit connection
- Patented quick adjustment for simple, safe setting and readjustment - without the use of tools
- Can be used as internal puller by repositioning the hooks
- Nitrocarburized spindle surface, wear and corrosion resistant
- Spindle remains smooth and clean - no need to grease or oil
- Crosspiece can be combined with other spindle/hook designs and lengths from the GEDORE puller construction kit
-
Dimensions and weights
- Weight [kg]: 3,85 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Number of arms: 3
- Width of hooked foot [mm]: 30 mm
- Thickness of hooked foot at tip: 3,5 mm
- Usable depth of hooked foot d2 [mm]: 18 mm
- Hydraulic spindle optional: 1.06/HSP1
- Width across flats [mm]: 22 mm
- Quick release lever available: Yes
- Usable clamping reach [mm]: 150 mm
- Clamping width (max.) external pulling [mm]: 160 mm
- Clamping width a2 (max.) internal pulling [mm]: 220 mm
- Clamping width a2 (min.) internal pulling [mm]: 100 mm
- Spindle thread size: G 1/2 x 210
- reversible arms available: Yes
- Tractive force (max.) [N]: 10,0 N
- Tractive force (max.) [t]: 5
