Impact socket 1" hex 32 mm
R83003211
/ Code no. 3300660
Impact socket 1" hex 32 mm
R83003211
/ Code no. 3300660
Price on request
Product line
EAN
4060833006606
Product description
- Machine-operated, fixing with safety ring / pin
- Phosphated surface
- Design according to DIN 3129, ISO 2725-2
- Square drive as per DIN 3121 - H 25, ISO 1174
- Chrome-molybdenum steel
-
Dimensions and weights
- Weight [kg]: 0,72 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Drive mount, square [metric]: 25,0 mm
- Drive connector square [inch]: 1"
- Actuation type: maschinenbetätigt
- Working length: 62,0 mm
- Insert-Ø 1: 52,5 mm
- Insert-Ø 2: 54,0 mm
- Insertion depth 1: 16,0 mm
- Insertion depth 2: 29,0 mm
- Material: Chrome‑molybdenum steel
- Standard: DIN 3129 ISO 2725-2 DIN 3121 - H 25 ISO 1174
- Surface: phosphated
- Test torque (min.) [Nm]: 4000 Nm
- Width across flats 1 [mm]: 32
- Safety: Sicherungsring und -stift
