Hydraulikaggregat Type LHU-35 Solution
LHU-35 Solution
/ Code no. 21950.000
Hydraulikaggregat Type LHU-35 Solution
LHU-35 Solution
/ Code no. 21950.000
Price on request
Product line
Product description
- For the first time in modern genset technology, the remote control takes over all settings that are normally made on the genset itself. The operator thus controls the entire tightening process from the remote control. Prepared for the use of different bolting modules.
- One-handed operation
- With new type of cooling air duct
- Completely closed protective housing
-
Dimensions and weights
- Total width [mm]: 275 mm
- Total height [mm]: 400 mm
- Total length [mm]: 570 mm
- Weight [kg]: 42,5 kg
-
Scope of delivery
- Parts list (Text): The hydraulic unit is delivered oil-filled and ready for use.
- Contents (Qty of pieces): 1
-
Technical characteristics
- Connection voltage [Hz]: 50
- Supply voltage V: 110 V
- High pressure l/min [bar]: 0,8/800
- Low pressure l/min [bar]: 3,0/320
- Tank size [l]: 3,5 l
