Cassette screwdriver type LDK-6
LDK-6
/ Code no. 14400.001
Cassette screwdriver type LDK-6
LDK-6
/ Code no. 14400.001
Price on request
Product line
Product description
- 360° rotatable hydraulic connection with integrated pressure relief valve
- Extra large hydraulic bores for minimum system heating
- Plug-in bolt system for lightning-fast replacement of the exchangeable cassettes without risk of crashing the drive part
-
Dimensions and weights
- Total length [mm]: 156 mm
- Weight [kg]: 2,4 kg
-
Scope of delivery
- Parts list (Text): Device incl. reaction arm and plug-in bolt system, tool case and operating instructions.
- Contents (Qty of pieces): 1
-
Technical characteristics
- Width cassette screwdriver (LDK) [mm]: 50 mm
- Width interchangeable cassette (WK) [mm]: 35 mm
- Torque (max.) [lbf·ft]: 4500 lbf·ft
- Torque (max.) [Nm]: 6200 Nm
- Torque (min.) [lbf·ft]: 260 lbf·ft
- Torque (min.) [Nm]: 350 Nm
- Height of swivel connection [mm]: 39.2 mm
- Height from centre of exchangeable cassette to beginning of rotary connection [mm]: 115/130
- Length from centre of interchangeable cassette to end of LDK housing [mm]: 156 mm
- Length from centre of interchangeable cassette to end of LDK reaction arm [mm]: 172 mm
- Radius interchangeable cassette [mm]: 34-60
- Width across flats 1 [AF]: 1.5/8"
- Width across flats 1 [mm]: 41
- Width across flats 2 [AF]: 3.1/8"
- Width across flats 2 [mm]: 80
