Double open ended spanner 12x13 mm
R05121213
/ Code no. 3301070
Double open ended spanner 12x13 mm
R05121213
/ Code no. 3301070
Price on request
Product line
EAN
4060833010702
Product description
- Acc. to DIN 895, ISO 3318, ISO 1085
- Short version
- Jaw set at 15°
- Chromium vanadium steel
- Matt satin chrome-plated finish
-
Dimensions and weights
- Total width [mm]: 28 mm
- Total height [mm]: 6 mm
- Total length [mm]: 136 mm
- Weight [kg]: 0,078 kg
-
Scope of delivery
- Contents (Qty of pieces): 1
-
Technical characteristics
- Width of head 1 [mm]: 26,6 mm
- Width of head 2 [mm]: 28,8 mm
- Head height 1 [mm]: 5,4 mm
- Material: Chrome‑vanadium steel
- Mouth position 1: 15°
- Standard: DIN 895 ISO 3318 ISO 1085
- Surface: satin‑matte chrome‑plated
- Width across flats [mm]: 12x13 mm
- Width across flats 1 [mm]: 12
- Width across flats 2 [mm]: 13 mm
