Optimized Design and New Interfaces
Opening and closing gate valves can be a daily challenge for both personnel and equipment, depending on the facility's conditions. Machines for operating gate valves and handwheels are a core business of GEDORE Torque Solutions. To make workflows more efficient on construction sites, in sewage plant pipe networks, and in hydropower plants, reliable and powerful gate valve machines are essential.
The gate valve machines of the LDA3-S series from GEDORE Torque Solutions are continuously developed and, in the latest development stage, LDA3-S, feature a robust 2-speed planetary gearbox for high breakaway torques. The 360° rotatable motor unit is powered by a strong power battery with 90 Wh/18 V/5 Ah and is gently shut off by proprietary microprocessor-controlled electronics to prevent sudden over-torquing. Additionally, the machines operate without a wear-prone slip clutch.
The technical features not only allow for the effortless opening of stuck gate valves but also enable the user to perform the tasks independently. Even handwheels with rising spindles are no problem.
The Analog and Digital Gate Valve Wrench from GEDORE Torque Solutions
Analog Gate Valve Wrench LDA3-S
- Breakaway torque from 600 to 1,450 Nm
- Steplessly adjustable breakaway torque
- Breakaway torque adjustment via potentiometer dial
- Multicolor status LED for visual information notification
- Weight-optimized for even more gentle and comfortable operation
- New hardware and software made by GEDORE for maximum update security
- Counter optional
- Secured torque throughout the entire battery life
- Low maintenance due to brushless technology
Digital gate valve machine LDA3 S Solution Core
- Breakaway torque 500 to 1,200 Nm
- System power 720 W
- Powerful 90 Wh (18 V/5 Ah) lithium-ion battery
- Integrated counter and countdown function
- Infinitely variable breakaway torque via the transflective digital color display
- Additional four-button control panel
- 360° rotatable motor unit for individually adapted ergonomics and one-person operation
